A
The probe model can be adapted according to the characteristics of the connector
Micro Probe
Board-To-Board Pogo Block
Pogo blocks provide a probing interface to board-to-board connector, turning traditional dedicated breakout boards into a customized platform for DC level, analog signals and RF signals (up to 10 GHz).
Not only does TRANTest’s pogo blocks help reduce the cost of testing, but also provide higher testing efficiency through the optimization of contact with connectors.
Overview
Connector Type
All kinds of connector
Pitch
≥ 0.175mm
Resistance
< 50mΩ (Pitch dependent)
Temperature
-40 ~ 85℃
Current Rating
0.5 ~ 2A
No.1
Precision alignment
No.2
Customized design
No.3
Easy to install
No.4
Low cost & high lifecycle
Features
01.
02.
B
High stability structure design and excellent product life cycle
03.
C
Achieve higher efficiency through the optimization of contact with connectors
Product Details
